    Metal Chanel Roll Forming Machine Chain Driven PLC Control 22KW With Reducer

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SM-CT
    Certification : CE,SGS,ISO
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 5 sets per month
    Delivery Time : 90 days after deposit
    • Product Details
    • Company Profile

    Metal Chanel Roll Forming Machine Chain Driven PLC Control 22KW With Reducer

    22KW With Reducer Metal Cable Chanel Forming Machine Chain Driven PLC Control



    Technical Parameter

    Decoiler

    1) Material width:460-520mm
    2) Material weight:5000kg
    3)
    Max Coil Width: 1250mm

    4) Expansion: hydraulic decoiler

    Level

    1) Working rolls: up 3/down 4
    2) Flatting bound: Material thickness 1-2mm
    3)
    Max Leveling Raw Material width: 1000mm

    Feeding

    Feeding Servo feeding motor: about 7.5KW,Yaskawa(Japanese Brand)
    Description: servo feeding can control the punching distance in precision, controlled by PLC, and the feeding tolerance can be+-0.05mm.

    The servo motor can control the speed, and can accept the input signal, and react quickly, and performance well

    The touch screen can display the rotating speed, the length and the quantity, it can be controlled by the manual and auto modes.

    Main roll forming machine

    1) Driven Type: 2'' chain
    2) Forming frame: 20 sets
    3) Forming variety: Bridge frame
    4) Material max width: 860mm
    5) Material max thickness: ≤ 2.0mm
    6) Forming width: 100-600mm
    7) Forming height: 50-100mm
    8) The diameter of the roller axis: 80mm
    9) Roll mould material: Gcr15, quenching treatment: HRC58-62
    10) Speed:4-5m/min

    Hydraulic cutting

    The cutter blade material: Cr12mov HRC58-62 degree

    Material of blade: CR12with heat treatment
    Cutting after forming: Cut the sheet after roll forming to required length
    Cutting motion: The main machine automatically stops and the cutting will take place. After the cutting, the main machine will automatically start.
    Length measuring: Automatic length measuring
    Tolerance of length: 6m+/- 1.5mm

    Control system

    1)Type: PLC Frequency Control System with touch screen
    2)PLC Brand: Japan Panasonic
    3)Encoder Brand: Omron

    4)Length Error: ±2mm

    Output table

    1)It is simple and used to load finished product.

    2)Length:6m


    Main Machine


    Name

    Quantity

    5 tons hydraulic de-coiler

    1 set

    Leveling &Feeding device

    1 set

    Roll Forming Machine1 set

    Punching Press machine

    1 set

    Punching moulds

    1 set

    Pre-cutting

    1 set

    PLC Control System1 set

    Out tables

    1 set

    Spare parts

    1 package


    We can produce machine as different profile drawing



    Customer's testing
