    7500w 0.7 - 1.2mm Shutter Making Machine 1 Year Warranty 12 Forming Stations

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SS-DR
    Certification : CE
    Price : negotiable
    Payment Terms : T/T L/C
    Supply Ability : 10 sets per months
    Delivery Time : 55-65 days after deposit
    • Product Details
    • Company Profile

    7500w 0.7 - 1.2mm Shutter Making Machine 1 Year Warranty 12 Forming Stations

    Door Rail Technical Parameter

    Technical Parameters (some depend on the final design)
    1StyleShutter Door Roll forming machine
    2Machine dimension (mm)9000*1750*1700
    3Total wight (Kg)7500
    4Forming steps14
    5Forming speed (m/min)Approx.12
    6Hydraulic station power(Kw)5.5
    7Diameter of shaft (mm)75
    8Hydraulic pressure(MPa)18-20
    9Electric condition380V/3Phase/ 50HZ
    10Power for hydraulic decoiler(Kw)5 and 3
    11Decoiler max capacity (Kgs)5000
    12Control systemPLC
    13Raw material thickness (mm)0.3-0.9
    14Effective width(mm)828
    15Material width(mm)1000
    16Main applicationtile roof
    17Serial numberD2011001

    Door Rail Main Components


    S.N

    Equipment name

    Quantity
    1.

    3T passive un-coiler

    1 set
    2.

    Feeding and leveling device

    1 set
    5.

    Main roll forming machine 12 stations drived by chain


    1 set
    6.

    Hydraulic cutting

    1 set
    7.

    Control system (including control box)

    1 set
    8.

    Out tables

    2 sets
    9.

    Water cooling system

    1 set
















    Advantage for Door Rail


    Feature:
    1. Cutter Material: Cr12MoV1 mould steel with heat treatment
    2. Shaft Material: 40Gr mould steel with heat treatment
    3. Roller Material: 40Gr mould steel with heat treatment, hard Chrome Coated
    4. Have fashionable, nice appearance and durable
    5. Delivery time: 30% deposit and balance before delivery
    6. Widely used in various industrial factory, villa building, civilian building, warehouse, etc

    7. We can manufacture various kinds of machines to satisfy our customer, you can also provided the drawings what you want or the samples, we will design the project for you accordingly


    Working Flow of Door Rail

    Decoiler----Feeding and Leveling---Roll forming---Cutting---Run out tables








    Profiles of Door Rail



    Picture drawing
