Description

Cable tray roll forming machine consists of uncoiler, leveling machine, servo feeding device, press machine, punching system, cutting device, guiding device, roll former and run-out table. With full and special experience, we can customize cable tray roll forming machines or cable tray roll forming production lines according to customers’ profile drawings and specifications.

Technical Parameter

Height of the profile: 60-200mm
Thickness: 1.0mm-3.0mm galvanized coils
Hydraulic punching moulds 3 sets
Rolling Speed: 0-12M/MIN
Roller Stations About 20 stations
Roller Material:Gcr 15with quenching
Shaft Dia: 75mm
Hydraulic cutting Power: 7.5 kw
Material Of Cutting: CR12 with quench treatment
Hardness HRC58-62
Tolerance: +-1.5mm
Electric Source:380V, 50HZ,3 phase
Weight About 8 tons
Profile adjustment Control by the rails&motor
Way Of Drive 1.5 inch chain
Size of machine Length 11000mm* Width 800mm* Height 1000m

Main Machine

Machine picture for reference

Packaging Details

1. Main plc control cable tray roll forming machine is covered by plastic film.
2. PLC computer control box, spare parts and other small parts are packed by wooden carton box.
Delivery Detail: 65 days after receipt of the advance deposit.
