    PLC Control System Cable Tray Roll Forming Machine Chain Driven 13m * 1.4m * 1.4m

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : CT
    Certification : CE
    Payment Terms : L/C, T/T
    Delivery Time : 60days
    Price : negotiable
    Supply Ability : 10+sets+per month
    • Product Details
    • Company Profile

    PLC Control System Cable Tray Roll Forming Machine Chain Driven 13m * 1.4m * 1.4m

    Working flow:


    Decoiler-----feeding----- leveling and guiding ------roll forming ------ punching-----cutting----output table

    Machine components:

    No.NameQty
    1.De-coiler1 Set
    2.Feeding and Guiding Device1 Set
    3.Roll Forming Machine1 Set
    4.Punching device1Set
    5.Hydraulic Cutting Device1 Set
    6.PLC Control Box1 Set
    7.Output table1 Set


    Techincal discription


    1.Decoiler
    (1)Max. Width: 600 mm
    (2)Inner Diameter: Φ350 – Φ600 mm
    (3)Out Diameter: 1500 mm
    (4)Max. Loading Capacity: 5000 kgs

    2.Leveling device
    (1)Max. Width: 400 mm
    (2)Thickness: 1.5 mm
    (3)Rollers for Leveling: 5 rollers
    (4)Material for Rollers: GCr15 steel
    (5)Hardness for Heat Treatment: HRC55 – 60°

    3.Roll forming MC
    (1)Rolled Material: Cold Rolled Steel Sheet
    (2)Material Thickness: 1-3 mm
    (3)Rollers: 13 Groups
    (4)Material for Rollers:45# steel polished and coated with chrome HRC55-60°
    (5)Shaft diameter:80mm
    (6)Shaft material:high grade No.45 steel after treatment
    (7)Motor Power: 15 kw
    (8)Rolling Speed: 2 – 8 m / min; Adjustable
    (9)Voltage:380V,3Phase,50HZ

    4.Punching device
    (1)Adopted with 3 independent 4 pillar hydraulic punches.
    (2)Length for Punch Table: 6 m
    (3)Motor for Hydraulic Punch: 5.5 kw
    (4)Hole-Punching Modular: 3 Pics

    5.Cutting device
    (1)Material for Cut-Off Modular:GCr12 steel
    (2)Hardness for Heat Treatment:HRC55-60°
    (3)Cut-Off Type:Hydraulic, Automatic Cut-Off
    6.Control system:
    Type: PLC Frequency Control System with touch screen
    PLC Brand: Japan Panasonic
    Encoder Brand: Omron
    Length Error: ±2mm

    7.Output table
    It is simple and used to load finished product.
    Length:6m

    Our Services


    Payment type: 30% T/T prepaid and balance should be paid before loading
    Delivery time: 60days after receving advance payment.
    Guarantee period: 12 months free service/ pay service all the machine life

    Installation and training:
    If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
    Without visiting,we will send you user manual and video to teach you to install and operate.
    If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.




    FAQ

    1) Q: Do you have after sales support?
    A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.

    2)Q: How do your machines compare with other big companies in this market?
    A: We are up to date with the latest technology and improve our machines accordingly

    3) Q: Will you deliver the right goods as ordered? How can I trust you?
    A: Yes, we will. The core of our company culture is honesty and credit.

    4)Q:What can you do if the machine broken?
    A:Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.

    5) Q:Can you be responsible for transport?
    A:Yes,please tell me the destination port or address.we have rich experience in transport.

    6) Q:Can you supply the raw materials?
    A:Yes,we can supply the galvanized steel coil,galvalume steel coil,color steel coil,and aluminum coil.
