(0.8-3)x1250 Simple Hydraulic Slitting Line Slitting Speed 0-40m/min

1. Technical Parameter

1. Material of processible coiled plate: galvanized steel coils, etc

2. Thickness of coiled plate 0.8—3mm;

3. Width of coiled plate 1250mm;

4. Precision of slitting width tolerance: ±0. 5mm;

5. Slitting speed: 0—40m/min;

6. Loading capacity of de-coiler machine (feeding machine): 8T;

7. Coil I.D: 508mm;

8. Coil O.D: 1400mm;

9. Knife pivot diameter of slitting blade: Ф200mm; material 40Cr;

10. Slitting blade: Ф180×Ф320×15;

11. Material of slitting blade: 6CrW2Si;

12. Hardness of blade: HRC60°—62°;

13. Recoiler I.D: 508mm;

14. Power: 380V three-phase electricity: 50Hz;

2. Composed Device

1. Hydraulic entry coil car

2. Hydraulic de-coiler

3. Hydraulic Pinch And Press Device

4. Head Cutting Machine

5. Slitting Machine

6. Scrap Winder

7. Pit

8. Tension Stand

9. Hydraulic recoiler

10. Hydraulic unload car
