    High Speed Automatic Light Keel Stud Steel Frame Roll Forming Machine 0.3-1.2mm thickness

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SM-ST
    Certification : CE ISO 9001
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram, D/P, D/A
    Supply Ability : 5 set per month
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    High Speed Automatic Light Keel Stud Steel Frame Roll Forming Machine 0.3-1.2mm thickness


    High Speed Automatic Light Keel Stud Steel Framing Roll Forming Machine 0.3-1.2mm


    Technical Parameter of Stud Machine

    Items

    Specifications

    Material of coil

    Material Thickness

    0.3-1.2 mm galvanized steel

    De-coiler

    Weight

    3 ton manual

    Forming system

    Rolling Speed

    10-12 m/min

    embossing

    1 set of rolls

    Roller Stations

    About 13 stations forming, 1 set of rolls for embossing

    Roller Material

    Cr40 Steel with quenching

    Shaft Material

    45# Steel Diameter 75mm shaft

    Hydraulic cutting Power

    4 kw

    Cutting
    system

    Material Of Cutting

    CR12 with quench treatment

    Hardness

    HRC58-62

    Tolerance

    +-1.5mm

    Cutting blade

    1 set of cutting blade

    Electrical control system

    Electric Source

    380V, 50HZ,3 phase

    Control System

    PLC Japanese Panasonic and Yaskawa Brand

    Way Of Drive

    1 inch single chain

    Size of machine

    Length 6500mm* Width 600mm* Height 800m


    Main Components

    Machine list

    3 tons manual de-coiler

    1 set

    Main roll forming machine

    1 set

    Cutting device

    1 set

    PLC Control box

    1 unit

    Hydraulic station

    1 unit

    Out table

    2 units






    Working Flow of Roll Forming Machine

    Feeding& Leveling—Rollforming——Cutting—Products collecting


    Photo Gallery






    Customer Visiting




    Our Exhibition




    Loading pictures



    Competitive Advantage

    1. Save space
    2. Easy installation
    3. Perfect service
    4. Excellent quality
    5. Operate easily



    After-sale Service


    1. The warranty is one year after the client receives the machine. Within the one year, we will courier the replacement parts to the client free of charge.
    2. We offer technical support for the entire life of our machines.
    3. We can send our technicians to install and train the workers in the clients' factories.
