High Speed PBR PBU R Panel Roof Wall Sheet Roll Forming Machine Tile Making Machine
Roofing system roll forming machine has a big range of metal sheet profiles. It includes trapezoidal panel, PV-4, PV-5, corrugated panel, roof tile panel, step glazed tile, metal deck panel, standing seam panel, ridge cap, rain gutter, double layer/ two layer, K span panel and ridge cap machine. Its products are widely used in roof and wall system in workshop construction and housing construction.
The normal machinable thickness range of our roof panel roll forming machine is 0.3mm-0.8mm, working raw material is Aluminum, PPGI, Galvanized steel, Galvalume steel etc. We design the machine according to your drawing, specially the pitch and height of each wave. This machine is used to form the pre-painted sheet/GI material to various roofing of the projects such as sports center, exhibition center, subway project, airport and stadium etc.
Different countries has different its own commonly used profiles and name. Here are some popular drawing profiles selected by our customers:
America Area:
1.ACANALADORA PARA LAMINA TR-90
2. ACANALADORA DE LAMINA R-72
3. CONFORMADORA PARA PLANCHA PV4/ PV6
4.CONFORMADORA PARA CHAPA R-101
5. CONFORMADORA PARA CALAMINA TR4
6. Acanaladora para lamina TR101
7. Perfil de telha Trapezio 25/1020
8.Acanalada de Onda
9. Acanalada 5-V
UK: Box profile roll forming machine
Africa: IBR 686 roll forming machine
Technical parameter:
| Rolling Speed | 0-30m/min |
| Feeding width | 1250mm |
| Thickness | 0.3-0.7mm |
| Control System | PLC |
| Roller Stations | about 20 stations |
| Roller Material | 45# forge steel, coated with chrome |
| Motor Power | 11kw main motor+3KW servo motor |
| Hydraulic power | 5.5kw |
| Hydraulic Pressure | 12Mpa |
| Tolerance | 1.5mm |
| Power supplier | 380V, 60HZ,3 phase |
| Way Of Drive | 1.2 inch single chain |
| Machine weight | about 12 tons |
Machine List
| Machine list | 5 tons hydraulic de-coiler | 1 set |
| Main roll forming machine | 1 set |
| PLC Control box | 1 unit |
| Hydraulic station | 1 unit |
| Safety cover | 1 set |
| Spare parts | 1 set |
working flow
Profile Drawing
Other Hot Sale Profile Drawings in USA
Machine Shows
Application:
Sussman Machinery(Wuxi) Co.,Ltd
The main products of factory is light gauge framing machine,
pre-painted steel forming machine, Glazed Tile forming machine,
Automatical C/Z Purlin forming machine, Floor Deck forming machine,
Guardrail forming machine, Down Pipe forming machine, The whole
carriage plate for car beam unit , Steel storage unit, etc. Totally
it has 100 types in 20 serious. The products are widely used in
warehouse, factory buildings, supermarket, Nursing homes, villas,
residential, greenhouse and other construction projects. Our
factory can meet the construction enterprises, automobile industry,
iron and steel production enterprises’s growing demand.
