Product Description:
Rack U Channel Roll Forming Machine is a specialized roll forming
apparatus used to produce racks. It is driven by a 7.5KW motor, all
powered by 380V, 50Hz, 3Phase. The rollers are 70mm in diameter and
the hydraulic cutting power is 5.5KW. It can form racks with widths
of 100mm and 200mm.
Ideal for producing racks, this Rack Forming Machine is efficient
and reliable. Its powerful motor and hydraulic cutting make it a
great choice for an industrial production environment. It is also
adjustable, with a forming width of 100mm and 200mm.
This Rack Forming Machine is a great choice for businesses looking
to produce racks with precision and speed. Its high-performance
motor and hydraulic cutting make it the perfect tool for industrial
production.
Features:
- Product Name: Rack Roll Forming Machine
- Dirve system: Chain driven
- Forming Speed: 3-5/min
- Material: 1.5-2mm Galvanized Steel, PPGI
- Control System: PLC
- Forming Width: 100mm, 200mm
Technical Parameters:
| Parameter | Value |
|---|
| Product Name | Rack Roll Forming Machine |
| Weight | 5T |
| Drive System | Gearbox |
| Cutting Length | 3-6m |
| Hydraulic Cutting Power | 5.5KW |
| Control System | PLC |
| Material | 1.5-2mm Galvanized Steel, PPGI |
| Roller Material | 45# Steel |
| Forming Width | 100mm, 200mm |
| Roller Diameter | 70mm |
| Forming Thickness | 1.5-2mm |
Applications:
Rack Roll Forming Machine—High Quality Forming Equipment from
Sussman Machinery
Sussman Machinery's Rack Roll Forming Machine (Model SM-SD-048) is
a reliable and efficient roll forming equipment that is designed to
provide superior quality product output. This roll forming
equipment is made with Wuxi-certified 45# steel to ensure superior
quality and durability. It is certified by CE SGS ISO and available
with a minimum order quantity of 1 SET. The price is discussed and
it is packaged in naked packaging with steel for delivery. Delivery
time is 60 days and payment terms are TT/LC. The machine has a
supply ability of 20 sets.
The Rack Roll Forming Machine has a forming thickness of 0.5-1.0mm,
power supply of 380V, 50Hz, 3Phase and material of 0.5-0.9mm
Galvanized Steel, PPGI. The roller diameter is 70mm. This machine
is capable of producing high-quality products with superior
precision and accuracy. This roll forming equipment is designed to
be user-friendly and efficient, and can be easily installed and
operated. It is an ideal solution for businesses that need to
produce a high-quality product in a cost-effective and efficient
manner.
Sussman Machinery's Rack Roll Forming Machine is a reliable and
efficient solution for businesses that need to produce high-quality
products in a cost-effective and efficient manner. This roll
forming equipment is made with 45# steel and is certified by CE SGS
ISO. It has a forming thickness of 0.5-1.0mm, power supply of 380V,
50Hz, 3Phase and material of 0.5-0.9mm Galvanized Steel, PPGI. The
roller diameter is 70mm. This machine is capable of providing
superior quality product output with superior precision and
accuracy.
Customization:
Sussman Machinery offers custom-made Rack Roll Forming Machine with
the model number SM-SD-048. This forming equipment is made in Wuxi
and is certified with CE SGS ISO. The minimum order quantity is 1
SET and the price will be discussed upon request. The packaging for
the product is naked packaging with steel. The delivery time is
within 60 days and the payment terms is TT/LC. The supply ability
is 20 sets. The forming motor power is 7.5KW, the weight is 5T, the
hydraulic cutting power is 5.5KW, the forming width is 100mm, 200mm
and the forming thickness is 0.5-1.0mm. If you want to get a
customized Rack Roll Forming Machine, Sussman Machinery is your
best choice.
Support and Services:
Technical Support and Service for Rack Roll Forming Machine
We provide comprehensive technical support and service for our Rack
Roll Forming Machine products. Our team of experienced engineers
are available to help you with any technical issues that might
arise. We can provide both on-site and remote support, and we are
committed to providing a timely and effective response to your
needs.
We offer a full range of maintenance services, including regular
maintenance checks, on-site repairs, and troubleshooting. We can
also help you with installation and setup, and any other technical
help you might need.
Our team is dedicated to providing the highest quality support and
service to our customers. We will always strive to ensure that your
experience with our Rack Roll Forming Machine products is as smooth
and trouble-free as possible.
