0.05-0.25mm 1250mm Width Stainless Steel Embossing Machine
Production Line
Embossing machine spefication
Our company specialized in designing and making metal sheet
embossing machinery,there are many series of steel embossing
machine which are suitable to you.
• Material (where applied to the figure): stainless steel.
• Harvesting before stamping sheet.
• Material sheet stamping: sheet 0.8-1.5mm
• Billet size (sheets): 1250 mm x 2500 mm.
• Sheet metal thickness (where it leaves an imprint): from 0.5 to
2.0 mm.
• Depth footprint (the depth of the picture after embossing): 50
microns = 1/20 mm = 0,05 mm.
• Speed stamping: not important (but not less than 3 metres per
minute).
• Type of stamping: unilateral model rolling. (Figure applied only
on the front side. Back ready sheet, remains smooth and clean.)
• Roller type: removable. (That we could change the picture.)
• In the proposal. Specify the cost of additional rollers.
Model | S1000 | S1400 | S1600 | S1900 |
Overall size(mm) | 2900*1200*1500 | 3300*1200*1500 | 3500*1200*1500 | 3800*1200*1500 |
Roller size | φ350*1000mm | φ380*1400mm | φ400*1600mm | φ450*1900mm |
Material of roller | 42CrMo | 42CrMo | 42CrMo | 42CrMo |
Roller hardness | HRC55-58 | HRC55-58 | HRC55-58 | HRC55-58 |
Way of embossing | Both up and down rollers embossing | Both up and down rollers embossing | Both up and down rollers embossing | Both up and down rollers embossing |
Embossing regulation | By screw | By screw | By screw | By screw |
Motor power(KW) | 7.5 | 11 | 15 | 15 |
Line speed | 0-18m/min | 0-30m/min | 0-40m/min | 0-45m/min |
1.Uncoiling Machine
1.Outline data: About 2000×900×1350mm
2.Coiled material mode:Φ200×1200mm air shaft
3.Support the weigh: ≤1000kg
4.Side with brake systems: Magnetic powder brake
2.Embossing Machine
Product Name | Metal embossing machine |
Material Specification | stainless steel |
Thickness | 0.05-0.25 mm |
Max. Coil Width | 1250mm |
Working Speed | 0-8m/min |
Motor power | 4kw |
Machine Dimension | About 2400mm*900mm*1300mm |
Total Weight | About 1500kg |
Voltage | 380v/3phase/50HZ or as customer's requirement |
Roller Material | 45# steel |
Width of Roller | 1200mm |
Embossing Pattern | As per the samples or the customer’s requirement |
3.Recoiling Machine
1.Outline data: about 2600×900×1350mm
2.coiled material mode:Φ200×1200mm air swelling shaft
3.support the weigh: ≤1000kg
4.Motor power: 220V 60Hz 3Phase 100 Nm torque motor,Speed:
0-18m/min
5.Gas rising axis side can be fine-tuned before and after
4. Flower Pattern
5.Applications
Wall cladding, facades, roofs and canopies, tunnels, column covers
or renovations, wall cladding, ceilings, bathrooms, kitchens and
balconies.
6. Embossing Machine Photo
