    0.7-1.2 Mm Roller Shutter Salt Door Machine Door Roll Machine With Perforated Collapsible Holes

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SM-SD
    Certification : CE,SGS,ISO
    Price : negotiable
    Payment Terms : T/T L/C, Western Union, MoneyGram, D/P
    Supply Ability : 10 sets per months
    Delivery Time : 60 days after deposit
    • Product Details
    • Company Profile

    0.7-1.2 Mm Roller Shutter Salt Door Machine Door Roll Machine With Perforated Collapsible Holes

    0.7-1.2 Mm Roller Shutter Salt Door Machine Door Roll Machine With Perforated Collapsible Holes


    Shutter Door Technical Parameter


    NO.
    Item
    Specification
    Material
    Raw material
    Galvanized steel
    Thickness
    0.7-1.2 mm
    Puncher
    Punching method
    Hydraulic post punching
    Machine
    Roller station
    12
    Shaft diameter
    60 mm
    Solid shaft material
    High grade 45# steel with Cr12 mov coated,
    quenching & tempering & treatment
    Roller material
    Gcr15, hardness 55-58 HRC
    Machine size
    About 5.8*0.8*1 m
    Machine weight
    About 3.5 tons
    Machine color
    As customer need
    Working speed
    8-12 m/min
    Cutter
    Hardness
    50-65 HRC
    Cutting tolerance
    ± 1mm
    Material
    Cr12
    Operate
    Hydraulic cutting
    Power
    Driving way
    Chain 1 inch
    Main motor
    5.5 KW
    Pump motor for cutter
    7.5 KW
    Voltage
    380V/50HZ, 3 Phase or Customized as customer' request
    Control system
    PLC brand
    Delta made in Taiwan
    Screen
    Touchable screen
    Language
    Chinese and English or add customer need language
    Decoiler
    Operation
    Manual
    Weight capacity
    3 Tons
    Receive table
    Operation
    Manual
    Length
    4 m

    Shutter Door Main Components

    S.N

    Equipment name

    Quantity
    1

    3 Tons passive un-coiler

    1 set
    2

    Feeding and guide device

    1 set
    3

    Main roll forming machine

    1 set
    4

    Hydraulic station

    1 set

    5

    Hydralic punching device1 set
    6

    Control system (including control box)

    1 set
    7

    Out tables

    2 sets
    8

    Spare Parts

    1 packages

















    Profiles of Shutter Door




    Advantage for Shutter Door


    1) We have about 12 years experience in steel machine line, experienced workers and engineers.
    2) We have CNC process to produce the rollers,grinder machine to smooth the frame.make it's more precise.and less tollerance.and after assebling,inspect the whole machine by trail production before delivery.
    3) On time delivery.Oversea engineers services available.
    4) Adopt newest tech across the world to ensure our quality, provide customers good quality machines with best price.
    5) Favourtie price for machine parts all the life.
