18.5kw U Post Profile Roll Forming Equipment 75mm Galvanized Steel

G300Mpa Galvanized Steel 2.0mm Thickness U Post Profile Roll Forming Equipment With Slotted Holes

1. U Post Machine Technical Data

Frame system	Cast iron structure
1. Roller station:	11 stations
2. Sheet thickness:	1.5-2.0mm CR/GI G300Mpa
3. Main machine power:	7.5KW motor
4. Rolling speed:	8-12m/min
5. Main shaft diameter:	70 mm.45# steel ,fine processment
6. Material of rollers:	GCr15,,HCR58-62,chromated on the roller
7. Way of drive:	chain drive 1.0inch
8. Way of cutting:	hydraulic cutting
9. Cutting blade material:	Cr12Mov HRC58-62
10. Hydraulic station power:	5.5KW
11. Cutting Length tolerance:	+/-1.0mm
12. Hydraulic pressure:	20Mpa
13. Way of control:	PLC control,Siemens,German brand
14. Yaskawa inverter control	7.5kw
15. Omron/Koyo brand	encoder to measure the length
16. Touch screen,	made in China
17. Voltage requirements:	380v,50Hz 3Phase
18. Size of the machine:	approx 5.0m1.0 m*1.2m

2. C post machine main components

Decoiler→Feeding material into machine →punching device→Roll forming machine →Hydraulic cutting →Finished Products

Machine name	Quantity
2 Tons automatic decoiler	1 set
Servo feeding	1 set
Main roll forming machine	1 set
Hydrualic punching device	1 set
Hydraulic cutting system	1 set
4 meters out tables	1 ste
PLC control box system	1 set
Tool box	1 package

3. U Post Photo

4. U Post Machine More details

The C post roll forming line includes automatic decoiler, hydraulic punching, roll forming system, cutting equipment, hydraulic station, electric controlling system and supporter for finished products.

This line adopts PLC control, AC frequency and speed adjusting technology to realize continuous production automatically.
