    Hydraulic Steel Coil Cut To Length Machine 1250mm Automatic

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : RF-ST
    Certification : CE, SGS, ISO
    Price : negotiable
    Supply Ability : 10 sets/month
    Delivery Time : 60 days after deposit
    • Product Details
    • Company Profile

    Hydraulic Steel Coil Cut To Length Machine 1250mm Automatic

    1250mm Width Automatic Hydraulic Steel Coil Cut To Length Machine,Steel Small Cut To Length Line

    1. Technical Parameter


    Coil weight from 200 kg (440 Lbs) to 5 tons (11023 Lbs)
    Strip size from 200 mm (8”) to 2000 mm (80‘’)
    Material thickness from 0.2 mm up to 1.0 mm


    No

    Name

    Unit

    Parameter

    1

    Materials


    CRS, GI, SS, Aluminum

    2

    Thickness

    mm

    0.2-1.0

    3

    Width

    mm

    1250

    4

    Coil I.D.

    mm

    Φ508

    5

    Coil weight

    Kgs

    5000

    6

    Max speed

    m/min

    0-20

    7

    Cutting precision

    Mm

    +-1.0 mm/two meters

    8

    Leveling roll

    piece

    Upper 4 / Lower 5

    9

    Feeding roll

    piece

    Upper 2/ Lower 2

    10

    Diameter of leveling rollers

    mm

    Φ65mm

    11

    Distance of leveling rollers

    mm

    70mm

    12

    Material of leveling roller


    GCr15

    13

    Power


    380V/50HZ/3PH

    14

    Size of the whole line(about)

    m

    About 15m(L)X5m(W)

    15

    The direction of whole line


    Depends on Customers' requirement

    16

    The color


    customized



    2. Cut to length line Work Process:


    How does coil cut-to-length line work?
    Coil cut-to-length lines work by taking metal coils or rolls from a metal mill and turning them into flat metal sheets of your specifications. These rolls are fed into the coil cut-to-length line which unspools, flattens, cuts, and then stacks them as flat metal sheets. Coil cut-to-length lines are an effective tool for producing sheet metal for your business.We offer light, medium, and heavy cut-to-length lines, each suited for your specific workloads.






    3. Cut to length line machine description

    The Cut-To-Length Line including uncoil to support the coil material, levelling it, and then cut it to the required length and stack it.

    The end product produced by a Cut-To-Length Line is a flat sheet of material cut to a very precise length tolerance.

    We can customize the Cut-To-Length line according to your requirement, there are several variables you should provide: the thickness of material, the type of material, length of the sheets to be produced, as well as annual volume to be processed all influence the line configuration and capabilities required for a successful installation.





    4. Composed Device


    1. Manual decoiler


    2. Hydraulic cutting


    3. Out put table
