    610-305 K Type Arch Roof Roll Forming Machine Arch Roof Panel Roll Forming Machine

    Ask Lasest Price
    Brand Name : Sussman
    Model Number : SS-RS
    Certification : CCC, SGS, ISO9001, CE
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10 sets per month
    Delivery Time : 55 - 65 days
    • Product Details
    • Company Profile

    610-305 K Type Arch Roof Roll Forming Machine Arch Roof Panel Roll Forming Machine

    610-305 K Type Arch Roof Roll Forming Machine, Arch Roof Panel Roll Forming Machine


    A K-Type Arch roof Roll Forming Machine is a type of roll forming equipment used in the construction industry to create arched or semi-circular structures, such as roofs and walls, from metal sheets. The machine works by continuously shaping and bending a flat metal strip into a desired curve using a series of rollers, until the desired shape is achieved.

    The name “K-Span” comes from the unique K-shaped cross-section of the finished product, which provides exceptional strength and stability, making it a popular choice for many construction projects. K-Span Roll Forming Machines are available in a variety of sizes and capacities, making them suitable for a wide range of construction applications.

    One of the key benefits of using a K-Span Roll Forming Machine is its ability to produce high-quality metal structures quickly and efficiently, with a minimal amount of material waste. The machines are also highly customizable, allowing manufacturers to produce structures in a variety of shapes and sizes to meet the specific needs of their customers.

    In addition to their efficiency and versatility, K-Span Roll Forming Machines are also known for their durability and low maintenance requirements. The machines are constructed from high-quality materials and designed to withstand the rigors of heavy-duty industrial use, ensuring long-lasting performance and reliability.

    Overall, K-Span Roll Forming Machines are an essential tool in the construction industry, offering a cost-effective and efficient solution for producing high-quality metal structures. Whether you are a contractor, builder, or manufacturer, a K-Span Roll Forming Machine is a valuable investment that can help you save time, reduce costs, and achieve exceptional results.

    Technical Parameter

    1. material width: 914mm


    2. effective width: 610mm


    3. roller stations: about 18 stations


    4. roller material: 45# steel, chrome plated


    5. main shaft material: 45# steel


    6. main power: 30Kw


    7. hydraulic station power: 4Kw


    8. hydraulic pressure: 12Mpa


    9. control system: PLC Panasonic


    10. machine size: 8500mm x1400mm x1200mm


    11. cutting blade material: Gr12Mov


    12. thickness: 0.4-1.5mm


    13. way of drive: single row of chain: 1.5.inch


    Machine Component


    5 ton passive de-coiler1 set
    Main roll forming machine1 set
    Control box1 unit
    Hydraulic station1 unit
    Out table2 units
    Arch machine1 unit
    Sew machine1 unit
    Portable wheels2 unit

    Main Fetures & Components of the Machine


    1. The structure is simple and the appearance of the machine is beautiful because we adopt the shape- steel structure and process as a whole after welding, it has the ability of strong loading and stable operation when running the machine.


    2. All the components of the machine are from brand-famous enterprise so that they ensure the machine normal function very effectively.


    3. We adopt the automatic length-fixed forming and cutting to guarantee the length to be precise and the finished product clear without deforming.


    4. It's very easy to install the equipment and suitable for producing in the factory.


    5. The machine has features of low noise and high efficiency.


    Profiles



    Forming Machine Pictures



    Feedback Pictures:

    Application:
