Mexico Roladora KR18 KR24 Z Shape Clip Lock Roll Forming Machine
The Z shape Clip lock is for KR18 and KR24 SSR roof sheet.
Metal panels are connected to the roof deck with lock strips and with clips to the seams. The standing seams seen on metal panels, also known as ribs, are locked together at the seam. This lets the metal panels slide backwards and forwards with ease, allowing free expansion and contraction of the roof.
The metal panels in standing seam roofing systems are locked together using clips. The clip is attached over the male part of the panel, and the next panel is fastened over the first one by snapping in on top of the clip. With the aid of these clips, the panels can glide up and down the underlayment without causing any wear and tear.
A piece of metal bent in the shape of the letter Z, the z bar fills the gaps between the ridge and ribs of the roof. This prevents water from passing through the gaps, thereby protecting the metal panels. After installing z bars, the standing seam roof can be locked into the ridge capping.
We can make the Z shape to meet your requirements, 90 degree and 180 degree.
| Material of coil | Material Thickness | 0.5 mm-1.0 mm galvanized steel |
| De-coiler | Weight | 3 ton manual |
| Forming system | Rolling Speed | 10-12 meters/minute |
| | Roller Stations | About 16-18 stations forming |
| | Roller Material | Cr40 Steel with quenching |
| | Shaft Material | 45# Steel Diameter 60mm shaft |
| | Maim Motor Power | 5.5 kw |
| | Hydraulic cutting Power | 4 kw |
| Cutting
system | Material Of Cutting | CR12 with quench treatment |
| | Hardness | HRC58-62 |
| | Tolerance | +-1.5mm |
| Electrical control system | Electric Source | 220V, 60HZ,3 phase |
| | Control System | PLC Control |
| | Weight | About 3 tons |
| | Way Of Drive | 1 inch single chain |
| | Size of machine | Length 5500mm* Width 600mm* Height 800m |
Application:
Portable metal roof roll forming machine export standard packages details
1.Nude,with waterproof cloth and stow-wood.Imported computer control system packed with waterproof cloth and card board.
2.This producing line is maintained free of charge for 24 months.When the machine is used in China, we will install and debug the machine for free; if it is used at abroad,we will send the professional technician to debug.Buyers should take all the fees for technicians travelling abroad.
3.All the parts in the roll forming machine is free to maintain all the life,if in 24 months our company bear the cost for
exchanged the broken part like the new parts cost and express cost,if more than 24 month,we also free to maintain the broken parts ,but for send the new parts,the buyer need bear the express cost.
